Industrial Touch Display I7-12700 CPU 12 Cores+20 Threads 16G RAM ASUS PRIME H510T2
Feature :
. Our device adopts surge protection design, Add electromagnetic ring anti-interference electrical components,the device can match EMC
interference immunity standard.
. Ten-point precision touch capacitor, good reflaxes, no blind spots, use LED panel of original module of intertantion large factory , rich color ,
average brightness.
. Aluminum alloy material ensure enclosed dustproof , design of heat dissipation structure inside the machine, it realizes the technology of
efficient heat dissipation without holes.
. Cloud service post remotely, support LAN/WAN, upgrade the whole transmission speed, save labor cost.
Parameter :
| General | CPU | RAM | Hard Disk |
power source 100-220V, Screen 27", 2K UHD 2560*1440, 250 nits,
display card: UHD 770 , | Cpu: i7-12700, Max frequency: 4.9GHz Cache memory:25M, 12 cores+20 threads | 32G DDR4 | 1TB_SSD M2 |
| K/B: Spanish |
Motherboard: ASUS PRIME H510T2/CSM, Intel H510 Chipset,
Memory supporting Max 64GB,DDR4,3200Mhz,Dual channel menory architecture, |
Internal I/0 connectors:Front USB (Iotal 6 ports), 1x,USB 3.2 additional 2-USB 3.2 ports,1x,USB 2.0 additional 4-USB 2.0 ports
D-Sub port,1x
HDMI port,1x, Realtek RTL8111H 1Gb Ethernet port,1x
|
Audio jacks, 2 x
DC Power Connector ,1x,Fan and Cooling related
4-pin CPU Fan header,1x
Power related
4-pin +19T Power connector, 1x
SATA power connector,1x
Storage related
M.2 slot (Key M),1x
SATA 6Gb/s ports,1x |
USB :
USB 3.2,additional 2-USB,
USB 2.0 additional 4-USB
AIO Systen related
1 x 2-pin internal DC power connector
1 x Stereo speaker connector
1 x DMIC header |
Miscellancous
1x Clear CMOS header
1x Chassis Intrude header
1x COM Port header
1x COM debug header
1x Front Panel Audio header (AAFP)
1x HDMI header |
1x HDMI Port
1x M.2 slot (Key E)
1x Speaker header
1x SPI TPI header (14-1pin)
1x VGA header
1x 10-1Pin System Panel header, Graphics
2x D-Sub(1 x port ; 1 x header)*
3x HDMI 2.0 (2 x ports ; 1 x header)**
1x LVDS header |
Ethernet net
1x Realtek RTL8111H 1Gb, System : Ubuntu Linux Product size: 61.5x56.2x18.5(cm), CTN size : 74x60x27cm, G.W./CTN: 13kg |
FAQ :
Q1: How to solve the quality problems after sales?
A1: (1) Take photos of the problems and send to us.
(2) Take videos of the problems and send to us.
(3) Send back the defective products to us if neccessory.
After we comfirm the problems, will give you the answer within 7 days.
Q2: Can we make our logo on the products?
A2: Yes. We can do logo as your requirement as well as your design project.And we also accept custom service.
Q3: What is your terms of payment?
A3: T/T
Q4: What is your minimum order quantity (MOQ)?
A4: As a standard policy, we accept MOQ of 100sets, and mixed items available, it still needs to confirm with our sales according to different
product lines.
